CA42/50/52 NAV menus & navigation examples Chapter 6
72
6.2.8 Set & drift
) The readings rely on data from external log and compass.
MENU
Load menu bar, and…
4,7
load display for “Set & drift”
Set & drift
0.6 kn
T
Relative
direction.
Speed.
True
direction
The set & drift display will show how fast the current is moving in
knots; in what direction (true) it is moving and what direction in
relation to the vessel (relative).
) To obtain information on actual and mean speed, velocity and water
speed – see the “Trim & highway display” in section 6.2.7.
30
60
90
30
60
90
