Simrad CA42 User Manual

CA42/50/52 NAV menus & navigation examples Chapter 6
75
6.5.1 Chart/cursor navigation
Cursor navigation is the easiest and most straightforward way of
navigation – point and go.
CHART
Shortcut to chart 1 display
Press the cursor key to activate the cursor, then move the cursor to
your destination
GOTO
Call up “Select NAV mode” window, and…
1
select “Cursor”
A course line will now be drawn from actual position (ship’s position)
to destination point (cursor’s position).
Next destination: While on the way, you can easily move the cursor
to the next destination, and when ready to change navigation leg…
GOTO
Press
[GOTO]
and
[2]
to…
2
“Restart to approaching point”
- A new course line will be drawn from ship’s position to destination.
It is possible to mix and match the data you require to have on the
screen e.g. ½ window for the chart display, ¼ window for the
navigation display, and ¼ window for the Trim & highway display,
maybe. The choice is yours. Refer to section 2.1 Fundamentals of the
PAGE and WINdow system.
To turn NAV mode off again:
GOTO
Press
[GOTO]
and
[3]
to…
3
“Turn NAV off” from active chart display
or…
MENU
Press
[MENU]
and
[4], [2]
to…
4,2
“Turn NAV off” via the menu
