CA42/50/52 Chart menus and INFO windows Chapter 3
31
3
From active chart display with cursor ON:
Plot and save cursor position as a waypoint; insert a location name
(cf.section 2.6), adjust the position by keying in new figures, change
the symbol (cf.section 2.5).
4
From active echo display:
Plot and save waypoint including actual depth from echogram, move
cursor and press [ENT] to save spot as waypoint. Add a name, symbol,
color, etc.
5
From active chart display with cursor ON:
You can quickly make a route by plotting cursor’s position, one after
another i.e. the present cursor position will be the first position of the
route you are about to make
.
Move cursor to next position, and press
[PLOT].
Continue in this manner till the route is completed. In case you
make a wrong plot, press
[CLR]
to erase the last plotted position.
Savetheroutewith
[ENT]
or exit the function with
[MENU]
to abandon
the route.
6
From active chart display with cursor ON:
To draw lines or to make a route is the same procedure, please refer to
point 5.
7
From active chart display with cursor ON:
Plot target at cursor position with preset target name, etc.
From chart display with cursor OFF:
The ship’s position will be plotted as target.
After plotting the target it will be saved in the memory, and you can
edit the target later on, either via the menu or directly from the chart:
Place cursor on the target symbol and press
[ENT]
to open an info
window with the heading “Target found”.Press
[1]
Edit user data to
open for new options of editing i.e. move target, delete target, alter the
position, insert a location name (cf.section 2.6) or select a new color
for the target number and symbol (cf.section 2.5).
8
From active echo display:
This function will set a vertical marker (line) at the current ping in the
echo display.
