101
12
Cable sockets
Designation Order No. Weight
[g]
E Square connector per DIN EN 175301-803A
cable diameter 6–10 mm, 3-pin +PE, max. 1.5
mm²
179-990-033
Cable sockets M12x1, 4-pin design, without LED
A Circular connector, straight, without cable
diameter 4–6 mm, 4-pin, max. 0.75 mm²
179-990-371 15
B Circular connector, straight, with 5-m integrally
extruded cable, 4-pin, 4×0.25 mm²
179-990-600 178
B Circular connector, straight, with 10-m integ-
rally extruded cable, 4-pin, 4×0.25 mm²
179-990-603 325
C Circular connector, angled, without cable
diameter 4–6 mm, 4-pin, max. 0.75 mm²
179-990-372 16
D Circular connector, angled, with 5-m integrally
extruded cable, 4-pin, 4×0.25 mm²
179-990-601 182
For other cable sockets, please refer to brochure No. 1-1730-EN, "Electrical Plug-In Connections."
E
Square connector and cable sockets, Fig. 10
EN
12. Accessories
