Skyjack SJ12 E - Page 109

109
SJ12 E, SJ16 E, SJ20 E
241914ACA
Pin Charts Section 5 – Procedures
Plug Pin # Wire # and Color Wire Function
CM1 ZAPI Controller Plug A
JA 1 24 Blue/Black 0V reference Output for Steer Left solenoid Valve 4H-24
JA 2 29 Blue/Yellow 0V reference Output (pulsed) for Beeper BP-29
JA 3 08C Purple/White 24V Input B+ from S10 Idle/PLTF/Base Key switch for Platform Signal
JA 4 08L Purple/White 12V Output B+ Supply for LS1 Mast Position Limit switch, BP-29 Beeper, and Left Motor Speed Sensor
JA 5 Not used
JA 6 Not used
JA 7 08 Purple/White 24V Input B+ from Platform E-Stop for Platform signal
JA 8 37 Green/White 24V Input for Charger Cutout Interlock switch (ON when not charging)
JA 9 CHAR Blue/White Input from Channel A signal from Right Motor Speed Sensor
JA 10 08R Purple/White 12V Output B+ Supply for Right Motor Speed Sensor
JA 11 Not used
JA 12 Not used
JA 13 03C Green/Purple 24V Input B+ Supply from C1 Motor Contactor closed thru CB2 Circuit Breaker (supply power for Solenoid coils)
JA 14 Not used
JA 15 00L White 0V reference for Left Motor Speed Sensor, and Temperature Sensor
JA 16 Not used
JA 17 CHAL Blue/White Input from Channel A signal from Left Motor Speed Sensor
JA 18 CANL Green Communication CANBus Low
JA 19 CHBL Blue Input from Channel B signal from Left Motor Speed Sensor
JA 20 CHBR Blue Input from Channel B signal from Right Motor Speed Sensor
JA 21 00R White 0V reference for Right Motor Speed Sensor, and Temperature Sensor
JA 22 Not used
JA 23 19A Orange/Black 24V Output B+ Supply for Telematics (option)
JA 24 23 Black/White 0V reference Output for Steer Right solenoid Valve 4H-23
JA 25 14 Black 0V reference Output for Lift solenoid Valve 3H-14
JA 26 13B Orange 0V reference for Lower solenoid Valve 2H-13
JA 27 19 Orange/Black 0V reference for C1 Motor Contactor
JA 28 30R Blue/Red 0V reference for Right Motor BK1 Brake
JA 29 13 Orange 24V Output for Lower solenoid Valve 2H-13
JA 30 30L Blue/Red 0V reference for Left Motor BK1 Brake
JA 31 CANH Yellow Communication CANBus High
JA 32 TMPR Black/White Input signal from Right Motor Temperature Sensor
JA 33 TMPL Black/White Input signal from Left Motor Temperature Sensor
JA 34 Not used
JA 35 Not used
