Skyjack SJ12 E - Specifications (CE)

30
SJ12 E, SJ16 E, SJ20 E
241914ACA
Section 2 – Maintenance Tables and Diagrams Specications (CE)
Model SJ12 E SJ16 E SJ20 E
Weight * 913 kg 931 kg 1107 kg
Overall width 0.77 m 0.77 m 0.80 m
Overall length 1.37 m 1.37 m 1.37 m
Platform size (inside) 0.69 m x 0.91 m 0.69 m x 0.91 m 0.69 m x 0.91 m
Platform traversing 0.41 m 0.41 m 0.41 m
Height
Working height 5.48 m 6.55 m 7.77 m
Platform elevated height 3.66 m 4.72 m 5.94 m
Stowed platform height (railings up) 1.88 m 1.88 m 2.01 m
Drive height Full Full Full
Stowed platform height 0.75 m 0.75 m 0.75 m
Standard operating times
Lift time (rated load) 15 s 21 s 26 s
Lower time (rated load) 16 s 22 s 26 s
Chassis
Stowed drive speed
Forward 3.5 km/h 3.5 km/h 3.0 km/h
Reverse 3.5 km/h 3.5 km/h 2.6 km/h
Elevated drive speed 0.5 km/h 0.5 km/h 0.5 km/h
Gradeability (ramp angle [reverse/forward])** 25% 25% 25%
Tires (solid rubber) 254 mm x 101.6 mm 254 mm x 101.6 mm 254 mm x 101.6 mm
Hydraulic oil
Type ATF Dexron III ATF Dexron III ATF Dexron III
Tank capacity 5.3 L 5.3 L 5.3 L
2176AC
2.7 Specications (CE)Table
* Weights are approximate; refer to the serial nameplate for the specic weight.
** Refer to your unit’s Operation manual for the procedure on how to move your MEWP for transport
Model SJ12 E SJ16 E SJ20 E
Maximum Drive Speed
Stowed drive speed -
Forward
3.5 km/h (2.2 mph)
10 m/10 sec (20 ft/6 sec)
3.5 km/h (2.2 mph)
10 m/10 sec (20 ft/6 sec)
3.0 km/h (1.9 mph)
10 m/12 sec (20 ft/7 sec)
Stowed drive speed -
Reverse
3.5 km/h (2.2 mph)
10 m/10 sec (20 ft/6 sec)
3.5 km/h (2.2 mph)
10 m/10 sec (20 ft/6 sec)
2.6 km/h (1.6 mph)
10 m/14 sec (20 ft/9 sec)
Elevated drive speed -
Forward and Reverse
0.5 km/h (0.3 mph)
5 m/36 sec (10 ft/23 sec)
0.5 km/h (0.3 mph)
5 m/36 sec (10 ft/23 sec)
0.5 km/h (0.3 mph)
5 m/36 sec (10 ft/23 sec)
2198AA
