54
SJ12 E, SJ16 E, SJ20 E
241914ACA
Section 3 – System Component Identication and Schematics Battery Management System Harness
3.19 Battery Management System Harness
CANH-YL-22
CANL-GN-22
09-BN-22
00-WH-22
J1
TO AMPERAGE SENSOR
09-BN-22
00-BK-22
05B-RD-22
CANH-YL-22
CANL-GN-22
00-WH-22
05B-RD-22
VOLTAGE
REGULATOR
S00
C
D
B
A
PIN A - CANL - GN
PIN B - CANH - YL
PIN C - 00 - WHITE
PIN D - 09- BROWN
S00
05B
CANH
CANL
00
D
C
B
A
J1
M230102AB
