Skyjack SJ12 E Service Manual

41
SJ12 E, SJ16 E, SJ20 E
241914ACA
Hydraulic Parts List Section 3 – System Component Identication and Schematics
3.4 Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
C1-3 234390 CYLINDER, Multistage with cushion (SJ12 E)
C-4 234430 CYLINDER, Multistage with cushion (SJ16 E)
C-4 234130 CYLINDER, Multistage with cushion (SJ20 E)
C5 234078 CYLINDER, Steer
CV1 234711 VALVE, Check - Poppet
F1 234269 FILTER, Screen
F2 234709 FILTER, Element spin-on 7M
MB1 234720 MANIFOLD, Valve assy - Elec 24VDC EW/4W
OR1 234654 ORIFICE, Check valve - Lift cylinder
OR2 310056 ORIFICE, Fitting Assembly - Hydr w/ orice
P1 234703 PUMP, AP100/3.5 ext Tang no CVRS
RV1 234715 VALVE, Relief - Max VM01 HDM10 T.95-210
RV2 234716 VALVE, Relief - Cart DA size 8
SV1 234713 VALVE, Cartridge - 3W/2P #8 3000 psi
SV2 234714 VALVE, Cartridge - 4W/3P 3000 psi CC 8
SV3 151696 VALVE, Emergency lowering
