Skyjack SJ12 E - Torque Specifications

36
SJ12 E, SJ16 E, SJ20 E
241914ACA
Section 2 – Maintenance Tables and Diagrams Torque Specications
2.15 Torque SpecicationsTable
Location Description
Torque
(ft-lb)
Torque
(Nm)
Base
Rear Axle Mounting Bolts BOLT, Hex head (3/8"-16 x 1-1/2" Grade 5) 23 31
Counterweight Mounting Bolts BOLT, Hex head (1/2"-13 x 2-3/4" Grade 5) 50 68
Steer Cylinder Hose Ftg Jam Nut NUT, Hex head jam (1"-14 Gr. 5) 180 244
Location Description
Torque
(ft-lb)
Torque
(Nm)
Mast
Emergency Lowering Coil Washer N/A 4.5 6
Emergency Lowering Valve N/A 21 28
Mast to Base Mounting Bolts BOLT, Hex head (3/8"-16 x 1" Grade 8) 35 47
Lift Cylinder Mounting Bolts BOLT, Hex head (3/8"-16 x 1-1/4" Grade 8) 23 31
Lift Cylinder Plate Mounting Bolts BOLT, Socket head cap screw (1/4"-20 x 1-3/4" Grade 5 ZP) 75 102
2191AB
