166
SJ12 E, SJ16 E, SJ20 E
241914ACA
Section 5 – Procedures Wheels
5.10-4 Prepare the new rear wheel
If the bearings are provided separately, start with
step 1. If the bearings are pre-installed, start with
step 4.
1. Use solvent to clean the bearings. Let them dry.
2. Completely coat the inner and outer bearings with
grease. Be careful not to contaminate the grease
as this can cause internal damage and decrease
the life span of the bearings.
Recommended Grease Type
STARPLEX EP2
UNIREX EP2
SHELL GADUS S2
3. Install the inner and outer bearings in the bearing
cups with the tapered ends pointing in.
Outer bearing
Bearing cups
Inner bearing
4. From the rear side of the wheel, put the grease
seal on the hub with the tapered end pointing in.
Inner
bearing
Grease seal section view
5. Put a at piece of wood over the grease seal to
protect it. Then use a hammer to lightly tap the
seal into place.
To Next Page
