Skyjack SJ12 E - Mast Cable (SJ12 E)

50
SJ12 E, SJ16 E, SJ20 E
241914ACA
Section 3 – System Component Identication and Schematics Mast Cable (SJ12 E)
3.15 Mast Cable (SJ12 E)
M234306AA_service
P2
BASE INTERFACE
J1
MAST INTERFACE
TO LOAD CELL
JUNCTION BOX
APPLY EXTRA LABLE TO J1 WIRE
POSITION WIRE LABEL
4
08C-PU/WH-18
OUTDR JUMPER
8 07-RD-16 82
9
08-PU/WH-18 CAN HI
10
08C-PU/WH-18 CAN LO
11
08C-PU/WH-18
OUTDR JUMPER
1
2
3
4
5
6
7
8
9 10
11
12
13
14
15
16
1
2
3
4
1
2
3
4
5
6
5
6
07-RD-16
08-PU/WH-18
08C-PU/WH-18
00-WH-16
08-PU/WH-18
00-WH-16
07-RD-16
CANHI-YL-20
CANHI-YL-20
CANLO-GN-20
CANLO-GN-20
08C-PU/WH-18
SCANL
SCANH
08C-PU/WH-18
08C-PU/WH-18
SDRN
SDRN
TO LOAD CELL
JUNCTION BOX
J1
MAST INTERFACE
P2
BASE INTERFACE
