Skyjack SJ12 E - Floor Loading Capacity (AS;CE)

35
SJ12 E, SJ16 E, SJ20 E
241914ACA
Floor loading capacity (AS/CE) Section 2 – Maintenance Tables and Diagrams
2.14 Floor loading capacity (AS/CE)
NOTE
The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure
WARNING
Do not use tires other than the tires that Skyjack species for this MEWP. Do not mix different
types of tires or use tires that are not in good condition. Only replace the tires with the same
types that are approved by Skyjack. The use of other tires can make the MEWP less stable. If you
do not obey, there is a risk of death or serious injury.
Model
Total MEWP
weight
Total MEWP load
Wheel** LCP*** OFL***
SJ12 E
min* 913 kg 295 kg 820 kPa 8.1 kPa
max* 1140 kg 449 kg 1059 kPa 10.1 kPa
SJ16 E
min* 931 kg 355 kg 910 kPa 8.4 kPa
max* 1158 kg 510 kg 1167 kPa 10.4 kPa
2187AA
*
Min: Minimum MEWP weight (unloaded platform, no options/attachments)
Max: Maximum MEWP weight (platform loaded to capacity with options orattachments)
**
Wheel is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and
platform
***
LCP: Local concentrated pressure is a measure of how hard the MEWP presses on the area in direct contact
with the  oor/tire.
OFL: Overall  oor load (Pressure) is a measure of the average load the MEWP imparts on the whole
surface directly underneath the chassis. This has been calculated by dividing the MEWP weight by the
overall  oor area occupied by the MEWP (on wheels).
Note: The  oor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must
be able to withstand more than the values indicated above
Table
