SJ12 E, SJ16 E, SJ20 E
241914ACA
Section 2 – Maintenance Tables and Diagrams Maximum platform capacities (evenly distributed) (ANSI/CSA)
2.9 Maximum platform capacities (evenly distributed) (CE)
2186AB
Model
Wind rating
Total platform
capacity
Extension platform
capacity
Manual
side force
Tilt cutout
setting (side-to-
side x front-to-
back)
SJ12 E
0 m/s 227 kg 2 persons 227 kg 2 persons 400 N 1.5° x 2.5°
12.5 m/s 227 kg 1 person 227 kg 1 person 200 N 1.5° x 2.5°
SJ16 E
0 m/s 227 kg 1 person 227 kg 1 person 200 N 1.5° x 2.5°
SJ20 E
0 m/s 159 kg 1 person 159 kg 1 person 200 N 1.5° x 2.5°
2.10 Maximum platform capacities (evenly distributed) (AS)
2185AB
Model
Wind rating
Total platform
capacity
Extension platform
capacity
Manual side
force
Tilt cutout
setting (side-to-side x
front-to-back)
SJ12 E
0 m/s 227 kg 2 persons 227 kg 2 persons 400 N 1.5° x 2.5°
12.5 m/s 227 kg 1 person 227 kg 1 person 200 N 1.5° x 2.5°
SJ16 E
0 m/s 227 kg 1 person 227 kg 1 person 200 N 1.5° x 2.5°
SJ20 E
0 m/s 159 kg 1 person 159 kg 1 person 200 N 1.5° x 2.5°
2.11 Maximum platform capacities (evenly distributed)
(ANSI/CSA)
Model Wind rating Total platform capacity
Traversing platform
capacity
Manual
side force
Maximum
Platform
height
Tilt cutout
setting
(side-to-side x
front-to-back)
SJ12 E
0 m/s (0 mph)
227 kg
(500 lb)
2 persons
227 kg
(500 lb)
2 persons
400 N
(90 lbf)
3.66 m (12 ft) 1.5° x 2.5°
12.5 m/s
(28 mph)
1 person 1 person
200 N
(45 lbf)
SJ16 E*
0 m/s (0 mph)
227 kg
(500 lb)
1 person
227 kg
(500 lb)
1 person
200 N
(45 lbf)
4.72 m
(15 ft 6 in)
1.5° x 2.5°
12.5 m/s
(28 mph)
3.66 m (12 ft)**
SJ20 E*
0 m/s (0 mph)
159 kg
(350 lb)
1 person
159 kg
(350 lb)
1 person
200 N
(45 lbf)
5.94 m
(19 ft 6 in)
1.5° x 2.5°
12.5 m/s
(28 mph)
3.66 m (12 ft)**
NOTE
Occupants and materials are not to exceed the rated load Refer to the capacity label at the entrance of the platform
and the mast assembly for additional information and models equipped with options
