SLE SLE5000 Model J - Page 100

Page 100 (Model J)
3. Remove the nuts and washers (K) to release the blender manifold assembly (L).
4. Lift the manifold assembly (J) off the four chassis studs. Disconnect the O
2
cell (K).
16.6.4 Removal of the pressure regulators from the old manifold
1. Remove the pressure
regulators (A, B & C)
from the manifold block
(D) remove the screws
(E), two per regulator.
Note: that the old ‘O’ rings (F) should be discarded.

K



K
K
K

L




D
A
F
C


B

E
E
