SLE SLE5000 Model J - Page 101

(Model J) Page 101
16.6.5 Assembly of the pressure regulators to the new manifold
2. Using the original screws (E) refit the
pressure regulator (G) to the new
manifold (H).
Use the new ‘O’rings (I).
The process is the same for the
remaining regulators.
Note: Pressure regulator design may vary.
16.6.6 Modification of fresh gas port
1. Remove and discard the following
connector (A).
2. Fit the new elbow (B) supplied with
the kit.



H

G

E
E
I

A

B
