Page 90 (Model J)
16.4.3 Removal of the Backup Batteries
1. Disconnect all the battery
terminal leads.
2. Remove the four retaining
screws for the first two battery
blocks.
3. Remove the two batteries.
4. Remove the two fixing screws and washers (A),
securing the fixing bracket (B) for the third battery.
5. Slide the battery forward and lift clear.
6. Remove the two fixing screws to release the
bracket from the battery block.
