Somat eDAQ
lite
46
I2773-4.4 en
Test Control Control Panel [CTRL+0] Open the TCE control panel. 4.3
Get Test Status [CTRL+1] Check the current test status of the eDAQ
lite
. 4.4
Initialize Test [CTRL+2] Initialize the eDAQ
lite
in preparation for the test run. 4.3.1
Remote Control [CTRL+R] Suspend or resume remote control operation. 4.7
Prerun Options... Access a variety of tasks after initialization. 4.3.2
Transducer Checks Perform a variety of checks on transducer channels.
Rezero Display [CTRL+Z] Display and re-zero transducer channels for an initialized test.
Reference Shunt Checks Check the repeatability of shunt calibrations.
Preview Run Start a test run with all DataModes storage suppressed. 4.3.3
Start Run [CTRL+3] Start a test run. 4.3.4
Shunt Control 4.2.1
Install Shunts Install shunt calibration resistors during a test run.
Remove Shunts Remove shunt calibration resistors during a test run.
Interactive Triggering [CTRL+4] Open a dialog to control the values of the eight available interactive
triggers.
4.3.5
Run Time Display [CTRL+5] Open the run-time display window. 4.5
Stop Run [CTRL+6] Stop a test run. 4.3.6
End Test [CTRL+E] End the current test run. 4.3.7
Auto Range Options Configure the option to automatically use the minimum and maximum
values recorded in the last test run as the full-scale values in future
test runs.
3.2.8
Upload Test Data [CTRL+7] Transfer all or selected test runs stored in the eDAQ
lite
to a
user-specified PC disk file.
4.6
Upload SIE Only Transfer SIE data files stored in the eDAQ
lite
to a user-specified PC
disk file.
4.6.1
Upload SIF Only Transfer the SIF data file stored in the eDAQ
lite
to a user-specified
PC disk file.
4.6.2
Upload Test Setup Transfer the test setup file stored in the eDAQ
lite
to a user-specified
PC disk file. This option is not available when a test is running.
Save AOM File Not applicable to the eDAQ
lite
.
Menu Menu Option Description Section
