Somat eDAQ lite
FCS Setup Set Master Sample Rate Specify the master sample rate (MSR) as either 100000 Hz, the
standard MSR for the eDAQ
lite , or 98304 Hz, provided to support
power of two sample rates. Data sample and data storage rates must
be integer divisors of the MSR. The eDAQ
lite stores the MSR in
nonvolatile memory for access only after an eDAQ lite reset.
Therefore, TCE initiates a programmed reset of the eDAQ lite unit
when the parameter changes.
Set Reset Options Control options for initiating system resets. The only applicable option
is the no new run on FCS error reset option which prevents the
eDAQ
lite from attempting to start a new test run when a serious error
forces a reset. For normal operation, do not select this option so that
the eDAQ
lite can attempt to salvage as much of the test run as
possible. This option is not available when the test is initialized.
Set Clock Set the real time clock on the eDAQ lite unit based on the current date
and time setting on the host PC.
Reset Perform a programmed reset of the eDAQ
lite unit. Use this option
only if absolutely necessary, such as when the system is not
responding.
Delete RAM Disk Files Delete all resident test and data files from the RAM disk. Only use this
option if there is no test initialized on the eDAQ
lite and all test data
has been safely uploaded from the eDAQ lite .
Format RAM Disk Format the RAM disk on the eDAQ lite unit and erase all files,
including some test data files, from the RAM disk. This option is
available at all times even while a test is running. Because the
eDAQ
lite formats the RAM disk in the normal process of test
initialization, formatting the RAM disk is not typically necessary.
10.1
Diagnostics Access commands for troubleshooting purposes. 10.1
Test FTP Perform a diagnostic test on the eDAQ lite file transfer process (FTP)
functionality. This option is not available when a test is initialized.
Check RAM Disk Check the integrity of the eDAQ
lite RAM disk.
Upload Log Save the eDAQ lite log, which contains messages, warnings and
errors from TCE and the eDAQ lite , to a PC disk file.
Preferences Communication Preferences Configure the Ethernet communications with the eDAQ lite . 3.2.1
General Preferences Configure TCE application preferences. 3.2.2
FCS Specific Preferences Configure TCE preferences specific to the target eDAQ lite . 3.2.3
Remote Test Run Control Configure the preferences for using remote control. 3.2.4
Scope and Spectrum Configure the settings for scope and spectrum displays. 3.2.5
Run Time Display Configure the settings for run-time displays. 3.2.6
Group DVM Display Configure the settings for group DVM displays. 3.2.7
Menu Menu Option Description Section
