II-98
*The ES layout sequence can be changed by pressing the Rotation button on
the toolbar.
When selecting a 3-window screen structure (Three or more transducers
must be connected.)
Select the
PARALLEL button
in SCREEN
LAYOUT
Select any 3 checkboxes.
Select Display using the menu button, and
then press the L key
on Display Toolbar.
Press the L key using the Rotation button.
Note: The fish length graph, TS graph, and trace graph are valid only at
frequencies of 38, 70, and 120 kHz.
