4-5 NMEA input setting
4-5-1 NMEA input
(1) NMEA0183 input specifications
The NMEA input specifications are the same as those of NMEA1 and
NMEA3.
The table below shows the specifications.
Table 4-12 Input specifications
Item
Spec.
NMEA0183
Compliant with Ver1.5, Ver2.0 and Ver3.0.
Baud rate
4800bps
Data bit
8bit
Parity
None
Stop bit
1bit
Input level
Photocoupler input
(2) Connection method
NMEA1 is input from J30 connector pin number A/B. NMEA3 is input
from J30 connector pin number E/F.
Table 4-13 J30 connector NMEA1 and NMEA3 input signal connection
Pin No.
Signal Name
Signal Level
A
NMEA1_in_A
Photo coupler input
B
NMEA1_in_B
E
NMEA3_in_A
photo coupler input
F
NMEA3_in_B
(3) NMEA1 input specifications
NMEA1 input is used only for GPS input. The table below shows the input
sentence.
Table 4-14 NMEA1 data specifications
Header
Data
RMC
Latitude, longitude, Ship speed and course
GGA
Latitude and longitude
GLL
Latitude and longitude
VTG
Ship speed and course
ZDA
Sate and time
