II-102
The windows are displayed as shown below.
Display unit 1 Display unit 2
* The layout sequence of the ES can be changed using the Rotation button
on the toolbar.
When selecting VERTICAL for a 5-window screen structure (Four
transducers must be connected.)
Select VERTICAL.
Select all checkboxes.
Select display using the menu button, and
then press the L key using Display Toolbar.
Press the L key using the Rotation button.
Check.
