Ⅲ-IV-17
(3) Original output specifications
The original output is for outputting the water depth and sea bottom SV
value calculated by this system. The table below shows the water depth data
and sea bottom SV.
Table 4-18 Original data specifications
Header
Data
Explanation
Remark
SDDBT
Water depth
Complied with Ver. 2.0.
SDDBS
Water depth
SDDPT
Water depth
SDBSV
Sea bottom SV
Original of SONIC
CPRPORATION
SDSON
Echo Sounder
frequency, beam
(PorS), water
depth, sea
bottom SV, sea
bottom detection
rate, draft, PRF
Original of SONIC
CORPORATION
These data
can be output
only when
the baud rate
of 38400bps
is selected.
(4) Original output connection method
The original output is output from the pin numbers e/f, h/j and k/l of J30
connector.
Table 4-19 J30 connector original output signal connection
Pin No.
Signal Name
Signal Level
e
KCE300_out_A
RS-422+
f
KCE300_out_B
RS-422-
h
KCE300_out_A
RS-422+
j
KCE300_out_B
RS-422-
k
KCE300_out_A
RS-422+
l
KCE300_out_B
RS-422-
