Speco N8NXP - Call PTZ Function

37
Scan Setup
Click Scan button as shown below.
Use the direction buttons to set the left position of the camera and then click the Left button.
Use the direction buttons to set the right positions of the camera and then click the Right button. The scan
setup process is then complete.
4.5.8.2 Call PTZ Function
Call Preset
As shown in Figure 4-21, enter preset value and then click to call the preset. Click again to
stop.
Call Pattern
As shown in Figure 4-21, enter pattern value and then click to call the pattern. Click again
to stop.
Call Tour
As shown in Figure 4-21, enter tour value and then click to call the tour. Click again to stop.
Call Scan
As shown in Figure 4-21, enter scan value and then click to call the scan. Click again to
stop.
Rotate
As shown in Figure 4-21, click to enable the camera to rotate.
