FD controller area network (FDCAN) RM0440
2002/2126 RM0440 Rev 4
44.4.33 FDCAN Tx buffer transmission interrupt enable register
(FDCAN_TXBTIE)
Address offset: 0x00DC
Reset value: 0x0000 0000
44.4.34 FDCAN Tx buffer cancellation finished interrupt enable register
(FDCAN_ TXBCIE)
Address offset: 0x00E0
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. TIE[2:0]
rw rw rw
Bits 31:3 Reserved, must be kept at reset value.
Bits 2:0 TIE[2:0]: Transmission interrupt enable
Each Tx buffer has its own TIE bit.
0: Transmission interrupt disabled
1: Transmission interrupt enable
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. CFIE[2:0]
rw rw rw
Bits 31:3 Reserved, must be kept at reset value.
Bits 2:0 CFIE[2:0]: Cancellation finished interrupt enable.
Each Tx buffer has its own CFIE bit.
0: Cancellation finished interrupt disabled
1: Cancellation finished interrupt enabled
