Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 1 General knowledge of the integrated drive controller
◉ Always install on metal structures or other noninflammable objects;
Or it may cause fire risk.
◉ Never install in explosive environments
Or it may cause explosion risk
◉ Never place combustibles near the product
Or it may cause fire risk.
◉ Always support the body bottom during handling
Or the possible falling of the main body of elevator integrated drive
controller may cause risk of injury and/or property damage.
◉ The platform on which the product will be installed shall have
sufficient load bearing capacity
Or the contingent falling of the main body of elevator integrated drive
controller may case risk of injury and/or property damage.
◉ Don’t install it in the vicinity of sewage pipe or the points with
splatters
Or it may cause the risk of property damage.
◉ Prevent screws, washers and metal rods falling into the inside of
elevator integrated drive controller
Or it may cause the risk of fire or property damage.
◉ Make sure it is disconnected from the mains prior to wiring
Or it may cause risk of electric shock.
◉ The wiring can only be performed by trained and qualified
electricians
Or it may cause risk of electric shock.
◉ Always keep the AS380 elevated integrated drive controller properly
grounded at its grounding terminal E
Or it may cause risk of electric shock.
◉ Avoid confusing main circuit input terminals and output terminals of
elevator integrated drive controller
Or it may cause risk of property damage and/or explosion.
◉ Never make terminal ○
+
1/○
+
2 and ○
-
be shorted.
or it may case risk of fire and explosion
◉ Make sure the cover is placed in position prior to switching on
Or it may cause risk of electric shock and/or explosion.
◉ Don’t use soggy hands operating elevator integrated drive controller
Or it may cause risk of electric shock
◉ At completion of wiring the emergency stop safety circuit, carefully
check and make sure all the wirings are correct
Or it may case risk of hazard.
