STEP AS380 Series User Manual

Shanghai STEP Electric Corporation
Chapter 7 Parameter Table of Integrated Drive Controller
168
No.
Name
Factory
Setup
Scope
Unit
Remarks
F218
Medium speed PID adjustor
incremental P2
120.00
0.00～655.35
×
F219
Medium speed PID adjustor
integral I2
25.00
0.00～655.35
×
F220
Medium speed PID adjustor
differential D2
0.20
0.00～655.35
×
F221
High speed PID adjustor
incremental P3
140.00
0.00～655.35
×
F222
High speed PID adjustor integral
I3
5.00
0.00～655.35
×
F223
High speed PID adjustor
differential D3
0.10
0.00～655.35
×
F224
Low speed point switch frequency
F0
1.0
0.0～100.0
％
F225
High speed point switch frequency
F0
50.0
0.0～100.0
％
F226
Zero servo time
0.5
0.0～30.0
s
F227
Band-type Brake release time
0.25
0.00～30.00
s
F228
Current slowdown time
0.00
0.00～10.00
s
F229
Torque compensation direction
0
0/1
×
0：positive direction
1：negative direction
F230
Torque compensation gain
100.0
0.0～200.0
％
F231
Torque compensation bias
0.0
0.0～100.0
％
F232
Filtering time for feedback signal
of encoder
0
1～30
ms
F233
Feedback direction of encoder
1
0／1
×
1：positive sequence
0：negative sequence
F234
Motor phase sequence
1
0／1
×
1：positive direction
0：negative direction
F235
Motor no-load current coefficient
32.00
0.00～60.00
％
Unnecessary to set up nomally
F236
PWM carrier frequency
6.000
1.100～11.000
kHz
Do not adjust this parameter
under normal circumstances
F237
PWM carrier width
0
0.000～1.000
kHz
Do not adjust this parameter
under normal circumstances
F238
Regulator mode
1
0/1/2/3
×
Do not adjust this parameter
under normal circumstances
F239
Output torque limit
175
0～200
％
Do not adjust this parameter
under normal circumstances
F240
Input voltage of inverter
380
0～460
V
F241
Nominal power of inverter
KW
This is a read-only query data
F242
Phase angle of encoder
0.0
0.0～360.0
Degree
F243
Zero position correction of
encoder
0
0/2
×
Set 2 for zero point correction
F244
Spare
10002
F245
Selection of F246~F255
parameter function
0
0～65535
×
Modify this parameter, then
F246～F255 will have different
meanings
When F245=0, F246~F255 have the following meanings
F246
Overheating protection time for
radiator
50
000～65535
0.01s
Default protection in case of
radiator overheating for more
than 0.5 second
F247
Overspeed protection coefficient
12000
0～65535
0.01%
The default overspeed protection
threshold is 120%
F248
Overspeed protection time
100
0～65535
0.01s
Default protection in case of the
speed surpasses F247 value for 1
second
F249
Confirmation times for inputting
open phase
60
0～65535
Time
Default protection in case of
inputting open phase for more
than 60 times in a given moment
