Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 7 Parameter Table of Integrated Drive Controller
Bit 3 set as 0: main board input point X15 as fire return switch input point.
Bit 3 set as 1: main board input point X15 as firefighter operation switch
Input point.
When users set the parameter F35 on the handheld operator, it will guide the users to set
the parameter bit by bit instead of calculating and setting all in one time.
F36—— Band-type brake switch inspection mode. 0: no band-type brake switch inspection; 1:
inspection mode outside Hong Kong region. 2: inspection at Hong Kong region.
F40—— Weighing data offset. Observe the weighing percentage value with an operator when the
elevator is balance-loaded. Then set the F40 with the above value.
If such value is not set, the incorrect null position of weighing instrument will affect the
startup comfort when elevator is balance-loaded.
F41—— the self-study and parameter setting. These parameters need the handheld operator to set.
Only DTZZIII-DC-SC weighing instrument is valid.
No-load self-study command and the return data after the successful
no-load self-study.
Full-load self-study command and the return data after the
successful full-load self-study.
Activity range of weighing device sensor 0～10mm.
The parameter setting of weighing device and return data after
successful self-study.
Activity range of weighing device sensor 0～20mm.
The parameter setting of weighing device and return data after
successful self-study.
Activity range of weighing device sensor 0～30mm.
The parameter setting of weighing device and return data after
successful self-study.
Activity range of weighing device sensor 10mm～0.
The parameter setting of weighing device and return data after
successful self-study.
Activity range of weighing device sensor 20mm～0.
The parameter setting of weighing device and return data after
successful self-study.
Activity range of weighing device sensor 30mm～0.
The parameter setting of weighing device and return data after
successful self-study.
After inputting the corresponding self-study command, F41 will display 5 if it starts
self-study, and the inputted self-study command will display after studying successfully.
Otherwise, zero will display if it fail.
For self-study mode 1 and 2, it can resume only when the F41 display 6.
When conducting self-study, set the activity range of weighing instrument sensor before
starting the mode 1 and mode 2 self studies.
F43—— landing call buzzing/flashing and door-closing standby option when in attendant status.
This parameter is only valid in attendant status.
