STEP AS380 Series User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 8 Elevator Elevator Commissioning Guide
225
Function
Code
Name
Content
Scope
U
ni
t
Factory Setup
Remarks
F164
Type of weighing
device
0～99
×
99
See the following
descriptions for
details
F70
Light load uplink
gain
100
0-300
%
F71
Light load lowlink
gain
100
0-300
%
F72
Heavy load uplink
gain
100
0-300
%
F73
Heavy load lowlink
gain
100
0-300
%
F74
Light load height
gain
512
0-1024
F75
Heavy load height
gain
512
0-1024
F229
Torque
compensation
direction
Set torque
compensation
direction
0/1
×
0
0: forward direction
1: reverse direction
F230
Torque
compensation gain
Set torque
compensation
gain
0.0～200.0
％
100.0
F231
Torque
compensation bias
Set torque
compensation
bias
0.0～100.0
％
0.0
Parameter F164 has the meanings as follows:
F164 set value
Model of weighing
device
Acquisition method of light, heavy, full
and over load signal
Acquisition method of
compensation signal
0
DTZZ-III-DC-SC
Input open/close signal to the car top
board
Input weighing device signal by
CAN, and then calculate the
final compensation value by
weighing device signal, F193,
F194 and F195 parameters
1
DTZZ-II
Input weighing device signal by CAN,
and then calculate the result by weighing
device signal
Input weighing device signal by
CAN
2
DTZZ-II
Input open/close signal to the car top
board
Input weighing device signal by
CAN
3
DTZZ-III-DC-SC
Input weighing device signal by CAN,
and then calculate the result by weighing
device signal
Input weighing device signal by
CAN, and then calculate the
final compensation value by
