STEP AS380 Series User Manual

Shanghai STEP Electric Corporation
Appendix B Para. Fault List Summary
268
F232
Filtering time for feedback
signal of encoder
0
1～30
ms
F233
Feedback direction of
encoder
1
0／1
×
1：positive sequence
0
：
negative sequence
F234
Motor phase sequence
1
0／1
×
1：positive direction
0：negative direction
F235
Motor no-load current
coefficient
32.00
0.00～60.00
％
Unnecessary to set up
nomally
F236
PWM carrier frequency
6.000
1.100～
11.000
kHz
Do not adjust this
parameter under
normal circumstances
F237
PWM carrier width
0
0.000～
1.000
kHz
Do not adjust this
parameter under
normal circumstances
F238
Regulator mode
1
0/1/2/3
×
Do not adjust this
parameter under
normal circumstances
F239
Output torque limit
175
0～200
％
Do not adjust this
parameter under
normal circumstances
F240
Input voltage of inverter
380
0～460
V
F241
Nominal power of inverter
KW
This is a read-only
query data
F242
Phase angle of encoder
0.0
0.0～360.0
Degree
F243
Zero position correction of
encoder
0
0/2
×
Set 2 for zero point
correction
F244
Spare
No.
Name
Factor
y Setup
Scope
Unit
Remarks
F245
Selection of
F246~F255 parameter
function
0
0～65535
×
Modify this parameter, then
F246～F255 will have different
meanings
When F245=0, F246~F255 have the following meanings
F246
Overheating protection
time for radiator
50
000～
65535
0.01s
Default protection in case of
radiator overheating for more
than 0.5 second
F247
Overspeed protection
coefficient
12000
0～65535
0.01%
The default overspeed protection
threshold is 120%
F248
Overspeed protection
time
100
0～65535
0.01s
Default protection in case of the
speed surpasses F247 value for 1
second
