Chapter 4 The Wiring Of Elevator integrated Drive Controller
Table 4.2 conductor specification and fastening torque
Model AS380-
Connectable wire
specification (mm
2
)
Recommended wire
specification (mm
2
)
Fastening torque
(N.m)
2S01P1
2～6
2.5
1.5
2S02P2
2～6
4
1.5
2S03P7
2～6
4
1.5
2T05P5
8~14
8
2.5
2T07P5
8~14
14
2.5
2T0011
22~30
22
4.0
2T0015
22~38
20
9.0
2T18P5
30~60
30
9.0
2T0022
50~60
50
9.0
4T02P2
2～6
4
1.5
4T03P7
2～6
4
1.5
4T05P5
2～6
4
1.5
4T07P5
4～8
6
2.5
4T0011
4～8
6
2.5
4T0015
4～8
6
2.5
4T18P5
8～16
16
4.0
4T0022
8～16
16
4.0
4T0030
14～25
25
9
4T0037
35～100
35
9
4T0045
35～100
50
9.0
4T0055
60～100
60
18.0
4T0075
80～125
80
18.0
Important
Wire specification is decided in accordance with the conditions of surrounding temperature
50℃ and wire temperature allowable 75℃
The main circuit of integrated drive control adopted the open terminals; round crimping
terminal should be used for the open terminals. Please check the table 4.3 for the round crimping
terminal.
Table 4.3 round crimping terminal
Wire cross-section（mm
2
）
Terminal screw specification
Round crimping terminal
specification
0.5
M3.5
1.25/3.5
M4
1.25/4
0.75
M3.5
1.25/3.5
M4
1.25/4
1.25
M3.5
1.25/3.5
M4
1.25/4
2
M3.5
2/3.5
