STEP AS380 Series User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
47
Chapter 4 The Wiring Of Elevator integrated Drive Controller
4.6.3.2 main extension board SM09IO/C plug-in and port definition
and Configurable content introduction
Table 4.5 IO main extension board SM09IO/C plug in specification
Table 4.6 IO main extension board SM09IO/C Configurable content
JP1 input：
0
Emergency Levelling
1
earthquake
2
Back-up power
3
Overload
4
Full load
5
Light-load
6
Fireman
7
Elevator Lock-out
8
Self-tuning of Shaft Information
9
sealing star Detect
10
Back-up
11
Fire return
12
upward No 3 terminal
deceleration
13
downward No 3 terminal deceleration
JP1
OQ/180D-3.81-8P，green
JP2
OQ-C/180D-5.08-7P， green
JP3
OQ/180D-3.81-4P， green
Pin No.
Type
No.
location
description
JP3
JP3.1
Encoder B phase
JP3.2
Encoder A phase
JP3.3
0V
JP3.4
+12V
JP2
JP2.1
Y7
JP2.1
Y7 common port
JP2.1
Y8
JP2.1
Y8 common port
JP2.1
Y9
JP2.1
Y10
JP2.1
Y9Y10 common port
JP1
JP1.1
X23
JP1.2
X24
JP1.3
X25
JP1.4
X26
JP1.5
X27
JP1.6
X28
JP1.7
X29
JP1.8
X30
