Stihl MS 441

46 MS 441, MS 441 C
: Carefully pull off the cylinder (1).
Do not use pointed or sharp-edged
tools for this job.
219RA103 TG
1
: Remove the cylinder gasket (1).
219RA621 KN
1
– Examine and clean the sealing
face (arrow).
219RA107 TG
The sealing face must be in
faultless condition and undamaged.
Parts with damaged sealing face
must be replaced, b 8.6.3.
Always fit a new cylinder gasket
whenever the cylinder has been
removed.
– Position the cylinder gasket (1)
so that the tab (arrow) faces
towards the muffler.
: Fit cylinder gasket (1).
219RA622 KN
1
: Examine and clean the sealing
face (arrow) and remove any
gasket residues.
– Examine sealing faces on
cylinder inlet and exhaust.
219RA105 TG
The sealing faces must be in
faultless condition and undamaged.
Use a new cylinder if the sealing
faces are damaged.
: Slide wooden assembly block (1)
1108 893 4800 between piston
and crankcase.
1
219RA108 TG
– Wet piston, piston rings and
inside of cylinder with oil, b 17.
219RA109 TG
1
