Strasbaugh Software Calibration Procedures
Version 1.2 - April 18, 1996 8 - 13
The following variables are used only with the grind spindle
current read-out option. Their default values should be set to
zero when this option is not installed.
Label Typ. Value Function
V160 800 fine wheel minimum current limit
V161 1400 fine wheel maximum current limit
V162 800 coarse wheel minimum current
limit
V163 1400 coarse wheel maximum current
limit
Note: All timer values represent one tenth second increments
(e.g. 50 equals 5.0 seconds).
The following control variable applies to software revision
7AARV31A (6/95) and later.
Label Typ. Value Function
V235 195 fine wheel aircut in axis command
units (multiply # of microns by
19.685)
