Strasbaugh Operator Functions
Version 1.2 - April 18, 1996 4 - 21
5) Finish feed rate - enter the final feed rate for the fine
wheel in tenths of microns/second (e.g. for 1.0
microns/second enter 10). This is the feed rate that will
be used for stock removal between the rapid fine
thickness and the finish wafer thickness.
6) Finish dwell time - enter the dwell time in tenths of a
second. This is the amount of time that the fine wheel will
remain at the fine wafer thickness before ending the
grind cycle. The computer will place one digit to the right
of the decimal point (e.g. for 5.0 seconds enter 50).
Maximum dwell time is 99.9 seconds.
7) Wafer chuck position - enter the coordinate for the work
chuck position while grinding. The computer will place
three digits to the right of the decimal point (e.g. for
7.000 inches enter 7000). This number should be set to
place the center of the work chuck under the center of
the rim of the coarse grinding wheel.
