Objet260 User Guide 6 Operating and Maintaining the Objet260 3DPrinter
DOC-37004 Rev.E 6-38
6. Placethenewscraperbladeontothepinsintheholder,asshown.
Figure6-46Insertingthenewrollerscraperblade
7. Insertandtightentherollerscraperbladescrews.
Important:
l TightenthescrewsintheordershowninFigure6-47.
l Usethenewscrewssuppliedinthereplacementkit
Figure6-47Tighteningtherollerscraperscrews
8. Aftertighteningthescrews,inspectthebladeandmakesurethatitis
straight.Ifnecessary,loosenthescrewsandtightenthemagain,evenly.
9. ReturntherollerwastecollectorassemblyandtherightUVlamptothe
printblock.(Seesteps4to6onpage6-34in"CleaningtheRollerWaste
CollectorandInspectingtheRollerScraper".)
