Operation
Replacing the nurse call backup battery (option) (Continued)
A
Figure 21: Cord out switch position
If the 9V nurse call battery needs to be replaced, a message will appear on the footboard display. The battery is located
on the patient’s left side at the head end of the bed (B) (Figure 22 on page 32). No tools are required to replace the
battery.
B
Figure 22: Battery housing
To replace the battery:
1. Unplug the power cord from the wall outlet.
2. Separate the Velcro that holds the battery housing (B) to the litter frame and lift the battery housing until it is free
from the litter frame (Figure 22 on page 32).
3. Discard the battery.
Note: Follow local regulations for disposal or recycling of this part.
4. Reverse steps to reinstall.

Stryker S3 Specifications

General

Weight Capacity	500 lbs (227 kg)
Maximum Patient Weight	500 lbs (227 kg)
Bed Frame Material	Steel
Type	Hospital Bed
Bed Width	35 inches (89 cm)
Caster Size	5 inches (12.7 cm)
Electrical Requirements	120 VAC, 60 Hz
Width	35 inches (89 cm)
Power Requirements	120 VAC, 60 Hz
Power Backup	Battery backup available
Accessories	IV pole
Siderails	Yes
