Another option is to open the File Manager
window (path: <Menu> / File / File Manger),
select New File and press <ENTER>.
Note: Saving is not possible when the instrument is measuring the signal. The message
“Measurement in progress!” is displayed for about 3 seconds.
Note: When no measurements were performed and there are no results to be saved all save functions
are disabled.
Automatic Wave files saving
Wave files contain signal recording data and are also saved automatically in the
SD Card memory with an extension .WAV. To enable automatic saving several
conditions should be fulfilled:
1. SD card should be inserted and there should be enough space on it.
2. The wave recording should be switched on (path: <Menu> / Measurement /
Logging / Wave Recording / Wave Rec.: Continuous or On Trigger).
The wave file name is defined automatically using the same rules as for the logger
files. The default prefix for the wave files is R.
Note: During the measurement run with wave recording to the wave file the “note” icon is displayed.
Note: The wave files usually are big in size and may use enormous memory space. Since the wave
name is not displayed on the result view screen, the user should remember that wave recording
function is active and switch it off always when wave recording is not required.
Saving the setup files
The measurement configuration setup files
can be stored in the SD Card memory with
an extension .SVT either by means of <S/P>
push-button or by creating the <New File> in
the Setup Manager list.
There is no automatic option for the setup
files saving, but the instrument always
generates new setup name automatically
with default prefix SET.
