Tadano GR-700N - Service Data; Amounts of Oil and Coolant; Operating Speed

Y-1
Y-1
Service Data
1
WY01-2692E
Y-1 Service Data
1. Amounts of oil and coolant
(1L = 2.64172 × 10
-1
gal)
Item
Standard
value (L)
Remarks
Amount of oil
Hydraulic
oil
Total oil capacity 930
TADANO Hydraulic Oil LL
(TADANO Genuine)
Tank capacity 620
Speed
reducer
gear oil
Slewing 3.8 Mobilgear 600XP 320 (Exxon Mobil)
Winch
Main 6.1
Mobilgear 600XP 150 (Exxon Mobil)
Auxiliary 6.1
1st axle Hub section 2.9×2
Apolloil gear HE-S90 (Idemitsu)
or
Cosmo Gear GL-590 (Cosmo)
2nd and
4th axles
Carrier
differential
12×2
Planetary gear 2.6×4
3rd axle
Carrier
differential
17
Planetary gear 2.6×2
Torque converter and transmission
(total oil capacity)
38.5
TADANO Genuine Torque Converter
Oil
Brake fluid Service brake 2.1
TADANO Genuine Brake Fluid
DOT-5.1
Engine oil Engine 27
JASO Standards: DH-2 or higher
SAE15W-40
(SAE10W-30 for cold climates)
Grease 1
Daphne Eponex Grease SR No. 2
(Idemitsu)
Grease
(lower centralized lubrication distributor)
1 Nigtight LE-0 (Nippon Grease)
Fuel tank 400 Diesel fuel JIS K2204 #2
Amount of
coolant
Coolant
Total volume 45.3 (*1)
TADANO Genuine Long-life Coolant
Necessary volume of
long-life coolant
22.7 (*2)
Coolant additives
3.8
(or equivalent)
Cummins DCA4
(*1): 12.8 L (in engine), 21.8 L (in radiator), 6.0 L (in reservoir tank), 1 L (in pipe), 3 L (in oil cooler),
0.7 L (in hot-water heater) (total amount including long life coolant and coolant additives)
(*2): With mixing ratio of 50%
2. Operating speed
Item Standard value Remarks
Operating
speed
Telescoping
Extending 34.2 m/124 s
Retracting ―
Elevating
Raising 0° to 84°/58 s
Lowering ―
Winch rope
(hoisting up) speed
Main 131 m/min On 5th layer
Auxiliary 114 m/min On 3rd layer
Slewing 2.1 min
-1
△
0
346-605-90000
△
1
344-527-
00001
△
0
345-808-
11000
△
1
344-527-
10001
[NOTICE]
Standard values are values at time of vehicle shipment
from TADANO. Limit values are the limits at which
adjustment or part replacement is necessary.
