Tadano GR-700N - Automatic Transmission

Y-9
Y-9
Operation Check (Traveling Device)
78
WY05-3940E
2. Automatic transmission
[NOTICE]
Numbers indicate speedometer readings (units: km/h).
 ( ) Indicates lock-up ON/OFF point.

Indicates downshift points when the accelerator position is 90% or above.
(These do not need to be checked.)
 (★) Indicates the lock-up OFF point when the accelerator position is 90% or above.
(These do not need to be checked.)
(1 km/h = 0.6214 MPH)
[High position]
Power mode: OFF
Power
mode: ON
Manual shift
[Low position
]
F6 (High 4th)
F5 (
High 3rd)
F4 (High 2nd)
F3 (High 1st)
F6 (High 4th)
F5 (High 3rd)
F4 (High 2nd)
F3 (High 1st)
F6 (High 4th)
F5 (High 3rd)
F4 (High 2nd)
F3 (High 1st)
F4 (Low 4th)
F3 (Low 3rd)
F2 (Low 2nd)
F1 (Low 1st)
