5. Torque converter and transmission
5.1 Maximum allowable speed
Units: km/h (MPH)
Shift position High position Low position
1 14.8 (10.9) 7.0 (5.3)
2 24.6 (16.8) 10.7 (7.7)
37.9 (24.5) 14.8 (10.9)
D 52.0 (35.0) 24.6 (16.8)
R 24.6 (16.8) 7.0 (5.3)
[NOTICE]
Engine speed: 2000 min
-1
Check the meter indication.
Pay attention to the tachometer indication and do
not overrun the engine.
(Max. 2360 min
-1
)
Drive selection must be done with the vehicle at a
complete stop and with the brakes not applied.
The mechanism does not allow 4WD selection in
Low-speed drive.
5.2 Adding oil to the torque converter and
transmission
[NOTICE]
When checking the oil level, turn OFF the PTO and
air conditioner. Check at an oil temperature of 50°C
(122°F) when the oil level settles after the engine is
started.
Do not add too much or too little oil.
Prevent dust and water from entering when adding
oil.
1. With the engine stopped, add oil through the oil
filler port on the top of the torque converter to the
prescribed level on the transmission oil level
gauge.
2. Put the transmission in neutral and start the
engine. While idling (700 min
-1
), continue to add
oil. Check that the oil level settles within the range
indicated by the
mark on the transmission oil
level gauge.
Total oil amount: approximately 38.5 L (10.2 gal)
