Tadano GR-700N - Back Camera, Drum Camera

85 85
Z-14
IWZ03-709003E
WZ03-7090E
View System
Z-14
Z-14
6
344-931-80000
1
344-952-20000
1.3 Back camera, drum camera
Back camera (option) Cable for back camera
(See Cable G)
Drum illumination lamp (option)
Drum camera (option)
Cable for drum camera
(See Cable G)
Controller (power box)
1-pole connector: CN840 (back camera)
Connect the (No. [22] G).
2-pole connector: CN841 (drum camera)
Connect the (No. [40] R).
For drum camera (connection to camera 2)
For back camera (connection to camera 1)
Detail A
233
YB
CN887M
Y/R
174AA
Insert the terminal of harness for drum illumination
lamp to this unused terminal.
G/W
367AA
W
S25-062
Y
S25-060
R
S25-061
B
S25-AA
B
S25-064
G
S25-063
BR
035AA
R/G
255AA
Y/W
818AA
R/B
278AC
14
CN887
Lamp
Harness for drum illumination lamp
Harness (slewing table, right)
Electric circuit (section A)
A
