Tadano GR-700N - Jib Slide Plate

Y-1
Y-1
Service Data
6
WY01-2692E
5.2 Jib slide plate
(1 mm = 3.93701 × 10
-2
in)
Location used
Standard thickness
(mm)
Replacement
standard (mm)
Remarks
Limit value
Jib 1 Front
Lower 12 9
Side - -
Jib 2
Front
Lower 12 9
Side - -
Rear
Upper corner
Upper 30 27
Side 35 33
Side 15 13
Jib 3 Rear
Upper corner
Upper 25 22
Side 35 33
Side 15 13
