3. Service brake
[NOTICE]
The vehicle has two boosters; one for the front
wheel brakes and the other for the rear wheel
brakes.
Take care of spattering the brake fluid and the fluid
level in the fluid reservoir while bleeding.
1. With the sufficient compressed air in the air
reservoir, depress the brake pedal and loosen the
air-bleed plug on the booster to bleed the circuit.
2. Then tighten the air-bleed plug before releasing
the brake pedal.
3. Repeat the above steps until the flowing brake
fluid contains no air bubbles. After the air bubbles
go out, tighten the air-bleed plug while letting the
fluid flow out.
Booster
[NOTICE]
There are two wheel cylinder air-bleed plugs each
with each axle.
4. Bleed the wheel cylinders in the calipers of the
axles in the steps same as above.
Caliper
