Tadano GR-700N - Comparison Table (Connector No., Usage and Coordinate)

76
WZ04-5021E
76
Z-13
Z-13
Harness (Lower)
Z-13
Z-13 Harness (Lower)
1. Harness (main and engine)
1.1 Comparison table (connector No., usage and coordinate)
CN No. Usage
Harness
diagram
coordinate
CN001
Hydraulic suspension pressure source solenoid
valve (SL01)
H-8
Suspension lock selection solenoid valve
CN002
Suspension P/C lock (SL02)
D-6
CN003
Suspension P/C free (SL03)
E-6
CN004
Accumulator lock (SL04)
CN005 Accumulator release (SL05)
Hydraulic suspension vehicle height adjustment
solenoid valve
CN007
Up (FL) (SL07)
D-4
CN008 Down (FL) (SL08) D-5
CN009
Up (FR) (SL09)
A-8
CN010
Down (FR) (SL10)
CN011 Up (RL) (SL11) D-5
CN012
Down (RL) (SL12)
D-4
CN013
Up (RR) (SL13)
A-7
CN014 Down (RR) (SL14) A-9
Outrigger extend/retract selection solenoid valve
CN020
Retracting (SL20)
H-7
CN021
Extending (SL21)
H-8
Outrigger jack/slide selection solenoid valve
CN022
Slide (FR) (SL22)
D-3
CN023
Jack (FR) (SL23)
CN024 Slide (FL) (SL24)
H-3
CN025
Jack (FL) (SL25)
CN026
Slide (RR) (SL26)
H-22
CN027
Jack (RR) (SL27)
H-21
CN028
Slide (RL) (SL28)
G-18
CN029
Jack (RL) (SL29)
F-18
Steering mode selection solenoid valve
CN030 Crab steering (SL30)
D-9
CN031
8-wheel steering (SL31)
CN033
Rear steering (SL33)
C-9
CN041
PTO (SL41) and lock up (SL49) solenoid valve
D-14
Transmission selection solenoid valve
CN042
R (SL42) and F2 (SL44)
E-11
CN043
F1 (SL43)
CN045
F3 (SL45)
CN046
High (SL46) and Low (SL47)
B-12
CN061
Air solenoid valve
(retarder control valve NC) (SL61)
E-9
CN062
Air solenoid valve
(retarder control valve NO) (SL62)
E-10
CN096
Positive control solenoid valve (SL96)
G-13
CN No. Usage
Harness
diagram
coordinate
CN400
Vehicle height detection (FL, L)
E-4
CN401
Vehicle height detection (FL, H)
E-4
CN402
Vehicle height detection (FR, H)
C-6
CN403
Vehicle height detection (FR, L)
B-7
CN404
Vehicle height detection (RL, H)
I-15
CN405
Vehicle height detection (RL, L)
I-16
CN406
Vehicle height detection (RR, L)
F-23
CN407
Vehicle height detection (RR, H)
F-22
CN408
Straight ahead detection SW
I-16
CN412 Coolant level detection SW E-17
CN413
Drive mode detection SW
E-10
CN417
Rear steering lock pin IN detection SW
I-17
CN418
Rear steering lock pin OUT detection SW
H-17
CN419
Torque converter oil pressure detector
E-13
CN420
Main speed sensor
G-12
CN421
Sub. speed sensor (pick-up sensor)
D-11
CN422 Outrigger length detector (FL) C-4
CN423
Outrigger length detector (FR)
G-4
CN424
Outrigger length detector (RL)
G-23
CN425 Outrigger length detector (RR) G-20
CN427
Torque converter oil temperature sensor
F-13
CN434
Outrigger control box
N-4
CN458
Differential lock detection SW
D-13
CN555
Temperature SW (50°C/122°F)
E-8
CN556
Temperature SW (85°C/185°F)
D-8
CN600
VCU CN1 (main board)
M-13
CN601
L-13
CN602
K-13
CN603
J-13
CN604 VCU CN1 (auxiliary board)
K-10
CN605
VCU CN2 (auxiliary board)
CN606
VCU CN3 (auxiliary board)
L-10
CN607
VCU CN4 (auxiliary board)
CN608
VCU CN5 (auxiliary board)
M-10
CN619
For VCU maintenance
M-5
CN680
Retarder controller
K-17
CN700
Head lamp High/Low selection (L)
I-1
CN701
Head lamp (L)
I-3
CN702
Head lamp High/Low selection (R)
B-1
CN703
Head lamp (R)
A-3
CN704
Head lamp relay
B-22
CN705
CN706
B-21
CN No. Usage
Harness
diagram
coordinate
CN707
Head lamp relay B-21
CN708
CN709
Combination lamp (R) B-1
CN710
CN711
Combination lamp (L) J-1
CN712
CN713
Over-side lamp (left center)
C-7
CN714
Over-side lamp (right center)
D-9
CN715
Over-side lamp (left rear end)
J-19
CN716 Over-side lamp (right rear end) J-21
CN717
Rear combination lamp (L)
I-18
CN719
Rear combination lamp (R)
I-20
CN723
License lamp
I-18
CN724 Side back lamp O-8
CN726
Level (Lamp)
I-6
CN727
DIAG SW (for retarder)
M-7
CN728
DIAG lamp (green) K-16
CN729
CN730
ECM DIAG/DPF regeneration SW
M-7
CN731
DIAG lamp (red) J-16
CN732
CN733
DIAG lamp (orange)
K-16
CN734
J-16
CN738
Electric retractable mirror motor (L)
K-2
CN739
Electric retractable mirror motor (R)
A-2
CN740
Retarder drum temperature sensor
(retarder body)
G-9
CN746
Grid heater
D-14
CN748
Alternator (I)
G-15
CN751
Back buzzer
I-22
CN752
Safety relay F-22
CN753
CN754
CN755
Grid heater relay D-22
CN756
CN757
Battery relay (-) side
E-23
CN758
D-23
CN760
E-23
CN761
CN762
Battery relay (+ side) (relay driving side)
D-22
CN763
Battery relay (+) side
CN765
Terminal assy
L-19
