7. Mass table
The dry weights of the major components are shown in the table below.
Refer the weights, and select appropriate hoisting devices when removing and installing the component.
(kg (lb))
Assy name Mass
(not including: boom, jib, elevating cylinder, slewing bearing,
5900 (13000)
Slewing bearing 520 (1150)
Slewing drive unit (including: hydraulic motor) 210 (460)
Center joint 85 (190)
Elevating cylinder 480×2 (1060×2)
Winch assy
(including: hydraulic motor)
Main winch 430 (950)
Auxiliary winch
Boom assy (including: boom telescoping cylinder) 8400 (18500)
Jib assy (including: jib tilt and jib telescoping cylinder) 1320 (2910)
Counterweight 510 (1120)
H-type outrigger assy (including: slide cylinder, jack cylinder) 820×4 (1810×4)
Engine 710 (1570)
Torque converter 240 (530)
Transmission 430 (950)
Retarder 110 (240)
Axle
(not including: steering cylinder)
1st axle 610 (1350)
2nd axle 870 (1920)
3rd axle 950 (2100)
4th axle 870 (1920)
Wheel assy (including: tire) 230×8 (510×8)
