Tadano GR-700N - Page 181

77
WZ04-5021E
77
Z-13
Z-13
Harness (Lower)
Z-13
CN No. Usage
Harness
diagram
coordinate
CN767
Fuse box (R)
A-19
CN768 B-19
CN769
C-19
CN770
A-20
CN771
Fuse box (R)
B-19
CN772
C-20
CN778 Upper power supply fuse (75 A) C-21
CN780
Center joint
A-13
CN781
A-10
CN782
CN783
A-11
CN784
CN785
A-12
CN788
Joint connector to “air”
C-13
CN789
B-12
CN790
Joint connector to “Cummins Insite”
C-22
CN792
ECM (Cummins)
A-16
CN793
ECM (Cummins)
C-15
CN929 DIAG SW (for retarder) M-7
CN945A
Side turn signal (L) J-3
CN945B
CN946A
Side turn signal (R) B-3
CN946B
CN950
Marker lamp
I-3
CN951
C-3
CN952
N-5
CN954
I-20
CN955
I-22
CN1003 CAN terminating resistance G-16
CN1004 Head lamp relay B-22
CN1008
Combination lamp (L)
K-1
CN1009
Combination lamp (R)
B-1
CN1017 Temperature SW (50°C/122°F)
E-8
CN1018
Temperature SW (85°C/185°F)
CN1030
Diode (accelerator SW)
M-15
CN1031 Diode (emergency accelerator SW)
CN1032
Diode (grid heater)
D-20
CN1059
Electrical box ground
C-20
CN1060
Diode (battery relay)
M-15
CN1075 Grid heater relay D-21
CN1092
Electric retractable mirror motor (L2)
F-3
CN1284
Diode (coolant level detection)
D-20
CN1298
Diode (PTO)
N-14
CN1392
Joint connector to “DPF”
G-18
CN1474
Return filter clogging detection SW
C-6
CN No. Usage
Harness
diagram
coordinate
CN1508
ECM DIAG SW (up)
L-7
CN1509
ECM DIAG SW (down)
CN1511
ECM DIAG SW (up/down)
CN1512
ECM DIAG/DPF regeneration SW
M-7
CN1514
Joint connector to “starter motor” H-14
CN1573
Marker lamp (option)
I-3
CN1574
C-3
CN1575
J-20
CN1576
J-22
CN1606 Water pump (W/P) G-10
CN1621
Diode (lock pin)
K-15
CN1622
Diode (DIAG lamp 1)
L-15
CN1623
Diode (DIAG lamp 2)
CN1630A
Emergency head lamp L-5
CN1630B
CN1680
Fuse box (L)
A-18
CN1681
B-18
CN1682
C-18
CN1683
A-18
CN1684
B-18
CN1685 C-18
CN1690
Fuse box (U)
B-23
CN1691
C-23
CN1692
CN1693
D-23
CN1720
Return filter clogging detection SW (GND)
D-6
JC02
Junction connector
N-12
JC03 N-17
JC04
O-17
JC05 O-12
JC06 E-20
JC07
O-17
RA8
Clearance lamp relay
L-16
RA11
Backup lamp relay
L-17
RA13
Retarder stop lamp relay
RA15
Side back lamp relay
L-18
RA16 Emergency transmission selection relay 1
RA19 Governor selection relay L-19
RA27 Outrigger accelerator relay M-16
RA75
Starter lock-out relay
M-17 RA95 Steering solenoid ground relay (lock pin OUT)
RA96
Steering solenoid ground relay (lock pin release)
RA97 PTO relay
M-18
RA98
Water pump relay
CN No. Usage
Harness
diagram
coordinate
RB1
Transmission power supply cutoff relay
M-19
RB3 PTO limiter relay
RB10
Battery power keeping relay
N-16
RB14
Starter cutoff relay
N-17
RB20 Coolant level detection SW relay
RC11
Mirror (R) extension relay
N-18
RC12
Mirror (R) retraction relay
RC13
Mirror (L) extension relay
N-19
RC14 Mirror (L) retraction relay
RF2-1
Emergency transmission selection relay
L-21
RF2-2
M-20
△
8
△
8
△
8
△
8
Applicable serial No.
: FE0636 --
△
