Y-5
Y-5
Adjusting Procedure (Electric)
41
WY04-2071E
3. Check that the switch satisfies the operating conditions in the table below.
(When the switch is turned ON, the LED lights up in green.)
Suspension
cylinder
Front left or rear left front right or rear right
Left switch
(CN401)
(CN404)
Right switch
(CN400)
(CN405)
Left switch
(CN403)
(CN406)
Right switch
(CN402)
(CN407)
Retracted OFF ON ON OFF
Normal traveling
state
(H = 145 ± 4 mm
(5.7 ± 0.16 in))
ON ON ON ON
Extended ON OFF OFF ON
△
