12 Technical specifications
DVB-S Tuner
Input frequency range 950 .... 2,150 MHz
Demodulation DVB-S: (QPSK)
DVB-S2: (8PSK, QPSK)
Symbol rate DVB-S: 2 ... 45 Mbaud/s, SCPC/MCPC
DVB-S2: 10 – 30 Mbaud/s (8PSK),
DVB-S2: 10 – 31 Mbaud/s (QPSK)
Input level range - 65 dBm to - 25 dBm
DBS Tuner input F socket
Input impedance 75 ohm
Roll off factor 35 %
Demultiplexing as per ISO 13818-1
Common Interface
Type 1 Common Interface slot for CI/CI+ modules
Power consumption max. 0.3A/5V
Card reader
Type 1 card reader slot for integrated CA system
Video decoding
Video compression MPEG 2 to (MP@ML) and (MP@HL)
MPEG 4 (H.264) to High Profile Level 4
JPEG decoding
Video format/Compression mode HDTV 1080i50: 1920x1080 25i, 16:9, H.264, MPEG-2
HDTV 750p50: 1280x720 50p, 16:9, H.264, MPEG-2
SDTV 576i50: 720x576 25i, 4:3/16:9, H.264, MPEG-2
(576i50 incl. 704/544/480/352 pixels per line)
Scaling 1080i50 —> 720p50, 576p50, 576i50
720p50 —> 1080i50, 576p50, 576i50
576i50 —> 1080i50, 720p50, 576p50
Video standard PAL
Image format control automatic
16:9->4:3 conversion Letterbox filtering/Pan & Scan
Simultaneous video
scaling to SCART socket HDTV (25/50 Hz Format) -> SDTV (576i/25)
Audio decoding
Audio compression MPEG-1 & MPEG-2 Layer I, II and III, MP3
Audio mode Dual (main/sub), Stereo
Sample frequencies 32 kHz, 44.1 kHz, 48 kHz
Audio parameters
Analogue output
L/R output level 0.5 V r.m.s. (nominal)
Output impedance 600 ohm
62
