Version: 1.06 127
Input/Output
Synchronization I/O Multipoint connection between CPU
Use: synchronize actions on several CPU in the same cabinet
Synchronization Input Use: to receive ‘Synchronization Output’ from other CPU
Vin: 0 5.5 V
Protection:
Over voltage: max. 33 V
Inversion: max. 29 V
Synchronization Output Use: to connect to ‘Synchronization Input’ of other CPU
Type: Current sinking
Voltage: max. 50V
Current: max. 45mA
Resistance: max. 60 ohms
NO PROTECTION
Temperature input Use: measurement of the card internal temperature
Internal input
Precision: 5 °C
Voltage input Use: measurement of the Input voltage
Internal input
Precision: 1 V
Temperature
Storage -20 to 70 °C
Working Standard: -5°C to 50 °C
Ruggedized: -20 °C to 70 °C
Hygrometry 15 to 95 % without condensation
Dimensions
Without connector Height x length x Depth: 150 x 83 x 29 mm
Weight 272 gr
