Version: 1.06 18
4.3. Working without Power Supply Card
If a power supply card is not required, the one from the CPU can be used.
In this case the CPU is placed at the first position in the Rack
The communication ports and/or the I/O cards are placed in any following slot.
Next to the ‘CPU’ card, you can leave slots empty
If you intend to use later a ‘Power Supply’ card and
don’t want to re-arrange all the cards, you can also
leave the first slot empty (slot ‘0’)
